310s stainless hlau daim phiaj tsis yog kub-resistant-lawv engineered kom vam meej nyob rau hauv infernos. Nrog 25% chromium thiab 20% npib tsib xee, no ultra-ARSTENITE Aloys luag tawm oxidation ntawm 1.150 degree) thiab shrug tawm thermal shocks uas warp lew cov hlau qis dua. Tsim los rau cov ntawv thov uas molten sults, cancer cua sov cov ntaub ntawv, Masnle Speedor Barrier ntawm kev muaj kev chaos muaj kev ntxhov siab thiab kev ua haujlwm txuas ntxiv.
Cov yam ntxwv tseem ceeb ntawm 310s Stainless Hlau:
Kub-Kub Kuj: Ua tau zoo txog1150 degree (2100 Qib F)Hauv kev pab cuam sib quas ntus thiab1035 degree (1900 degree f)nyob rau hauv kev pabcuam txuas ntxiv.
Oxidation & Corrosion Kuj: Superior tsis kam rau oxidation, sulfidation, thiab lwm hom kev kub-corrosion.
Tshuaj Muaj Tshuaj(Raug):
Chromium (cr): 24-26%
Npib tsib caug (ni): 19-22%
Carbon (c): Tsawg dua los yog sib npaug rau 0. 08%
Silicon (si): Tsawg dua los yog sib npaug rau 1.5%
Manganese (mn): Tsawg dua los yog sib npaug rau 2. 0%
Phosphorus (p): Tsawg dua los yog sib npaug rau 0. 045%
Sulphur (s): Tsawg dua lossis sib npaug rau 0. 03%
Hlau (FE): Tshuav nyiaj li cas
Cov Kev Siv Cov Ntaub Ntawv Feem Ntau:
Qhov cub cua sov & cua sov(Radiant tub, muffles, hlawv)
Boiler Qhov Chaw & Cov Khoom Siv Ua Haujlwm Thermal
Petrochemical & Cov Khoom Siv Hluav Taws Xob
Kilns, Ncu, & Tso Tawm
Lub zog tiam (roj turbines, hloov cua sov)
Muaj Cov Ntawv & Specifications:
Phaj Thickness: Feem ntau{{0 {}}. 5mm txog 100 hli(kev cai ntau thiab tsawg)
Dav & Ntev: Txheem thiab kev cai qhov ntev (piv txwv li, 1000mm × 2000mm, 1500mm × 3000mm)
Tus qauv:
ASTM A240(Stainless Hlau Phaj \/ Ntawv)
ASME SA240(Siab Hlais Av Siv)
En 1.4845(European sib npaug)
Cov Khoom Siv Neeg Kho Tshuab (Chav Chav):
| Ntiag tug | Tus nqi |
|---|---|
| Lub zog tensile | Ntau dua los yog sib npaug rau 515 MPa (ntau dua los yog sib npaug rau 75 KSI) |
| Paib lub zog (0. 2% offset) | Ntau dua los yog sib npaug rau 205 MPa (ntau dua lossis sib npaug rau 30 Ksi) |
| Elongation (% hauv 50 hli) | Ntau dua los yog sib npaug rau 40% |
| Hardness (Brinell) | Tsawg dua los yog sib luag rau 201 hb |
Qhov zoo dua lwm cov qib:
Zoo dua 304\/316: Cov ntsiab lus CR \/ NI txhim kho tshav kub ua kom tau.
Lwm Txoj Kev Los Txog 309s: 310s muaj cov oxidior oxidation tsis kam ntawm qhov kub heev.
Muaj nqi ntau dua li inconelRau ntau daim ntawv thov kom sov siab.
Fabrication & Vuam:
Luam ntawv: Tsis tshua muaj vim ua haujlwm hnyav (siv qeeb ceev, cov cuab yeej ntse).
Vuam: Zoo heev Veldability ntawm TIG, MIG, lossis SMAW (SIV 310 MATER HLAU).
Ib tug anerting: Pom zoo rau{{0 {0}} degree (1900-2050 degree f)ua raws los ntawm kev ua kom txias sai.
